    Capping orals a pictoral guide!

    This guide to manufacturing your own capsules is brought to you by Black Lion Research.


    Here we will make caps with 100mg active ingredient each.
    Ill give you a supply list and show you how to use a hand capsule press.
    In addition Ill show you how to use geometric dilution to measure and mix your ingredients properly. Failure to do this can result in severe dosage issues.
    Some caps will have 100 mg...some 2mg some 500mg unless geometric dilution is employed.
    Lets get started.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  2. #2
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    Supplies needed:

    Active ingredient 40g
    filler ingredient 180g
    Capping machine *
    Mortar and pestle
    400 gelatin caps-empty size -00-
    Digital scale

    * you will more than likely be using a 25 or 50 cap machine. Simply adjust accordingly.
    Each -00- cap will hold roughly 550mg of a dense powder. In this case we needed 220grams for 400 caps. You can estimate the total volume needed by hand filling one capsule, pouring out the contents and weighing it. From there multiply that number x the number of caps in your machine.

    ======================

    FILLING THE MACHINE WITH CAPS


    Attach the fill tray to the bottom portion of the machine. This is where the larger half of the caps go.



    Then pour in bottoms, cover the space on the bottom right with the pal of your hand and shake. The caps will fall into place.
    Last edited by brundel; 02-28-2013 at 11:00 AM.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  3. #3
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    Once full.


    Repeat with the tops.


    Attach the position tray and set the tops portion aside.
    Last edited by brundel; 02-28-2013 at 11:01 AM.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  4. #4
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    WEIGHING AND MIXING

    Geometric dilution. In order to be certain our active ingredient is evenly distributed throughout the mixture and to ensure consistent dosing in every capsule, geometric dilution must be employed. Watch this short video explaining and demonstrating geometric dilution.

    video


    40g active ingredient:


    Equal amount filler:


    I always go just a hair over in weight. I always did this with my gear and I pass on this rule of thumb to my supplements. Black Lion Products are ALWAYS just a tad overdosed.


    As seen in the video youll use a mortar and pestle to mix equal amounts of active and filler.


    Here is the final mix after performing geometric dilution.
    Last edited by brundel; 02-28-2013 at 11:08 AM.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  5. #5
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    FILLING THE CAPS

    Attach the rim guide.
    Pour the mixed powder onto the tray. This is the same technique for every cap machine 15 cap and 600 cap.


    Spread the powder out and fill the cap evenly.


    Use the tamp to pack the capsules.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  6. #6
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    PRESSING THE CAPS


    Once the caps are evenly filled.


    Press the portion with the tops onto the bottom portion and apply pressure. You will then have this:


    And we are finished. Dump them into a bin for counting and dispensing.


    And we are done
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  7. #7
    Senior Member
    ELITE MEMBER
    bdeljoose's Avatar


    Join Date
    Jul 2011
    Gender
    Male
    Location
    usa
    Posts
    947

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    90892263


    Good post. Should be a sticky.

  8. #8
    THE WAR PIG
    SUPER MODERATOR
    XYZ's Avatar


    Join Date
    Jun 2010
    Gender
    Male
    Location
    IM
    Posts
    5,456

    Thanks Thanks Given
    2
    Thanks Thanks Received
    3
    Thanked in
    2 Posts
    Rep Points
    2147483647


    Nice work!

  9. #9
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    Im gonna put some others up soon as well.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  10. #10
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    Hopefully guys will see it in the sticky section.
    Im gonna put up some more later. Maybe tonight.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  11. #11
    Registered User


    Join Date
    Mar 2011
    Gender
    Male
    Location
    earth
    Posts
    2,788

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    137490307


    very nice pic tutorial

  12. #12
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    Can you guys see all of the pictures? Someone said they cant see the pics in the first few posts.
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  13. #13
    Moderator
    MODERATOR
    TGB1987's Avatar


    Join Date
    Feb 2011
    Gender
    Male
    Location
    Pennsylvania
    Posts
    2,490

    Thanks Thanks Given
    1
    Thanks Thanks Received
    1
    Thanked in
    1 Post
    Rep Points
    490784410


    Very nice



  14. #14
    Registered User
    brundel's Avatar


    Join Date
    Aug 2008
    Gender
    Male
    Location
    Pedal to the metal
    Posts
    2,602

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    234871100


    TGB can you see the pictures in posts 2-4?
    BLACK LION RESEARCH Sign up for our newsletter! For product giveaways, news, contests and more.
    http://www.blacklionresearch.com/contact/

  15. #15
    Registered User
    hypo_glycemic's Avatar


    Join Date
    Dec 2010
    Gender
    Male
    Location
    USA
    Age
    47
    Posts
    2,685

    Thanks Thanks Given
    0
    Thanks Thanks Received
    0
    Thanked in
    0 Posts
    Rep Points
    749675402


    Capping orals a pictoral guide!

    On tapatalk,I can't see #2 or #3..
